SAFEPACE GUARDIAN AWARENESS CAMERA

The SafePace Guardian awareness camera, is designed for use on low volume roads such as campuses and private communities, captures images of vehicles that exceed the speed of your choice. Speeds are detected via radar unit of a connected SafePace sign. Speed-stamped photos as well as all speed data from your signs are transmitted to the SafePace cloud, which you can access from any device, anywhere. Images can be used to warn drivers or enforce speed limits.

Features:

• Photographs one approaching lane
• Designate violation speed limit
• Day and night use in all weather
• Powered by ac power supply
• Access data from anywhere

Compatible with:

• All SafePace sign models

Specs

Camera/Imaging

Resolution (H × V) Full HD, 1920 × 1080 pixels
Camera Lens CS mount; fixed focal length; suitable for day/night time operation
Number of traffic lanes 1
OCR Server-based; Front plate

Processor/Storage/OS

CPU 800 MHz Quad-core ARM A9
Memory 2 GB of RAM
Storage 4 GB of flash (non-volatile) storage
Buffer approximately 400 incidents (with typical settings)
Operating System Custom-built Linux

Illuminator

Required for night time operations; available on request



Internal/External External
Model AXTON Smart AT-32S-A 30° Infrared Illuminator (850nm)
Wavelength 850nm
Power supply voltage 24 V DC
Instant Current 2.8 Amps
Power consumption approximately 34 Watts

Electrical Specifications

Power supply voltage 12 V DC
Instant Current 0.4 Amps
Power consumption approximately 4.8 Watts

Mechanical Specifications

Operating temperature -20° C to 65° C
IP rating IP65
Camera Housing Aluminum, light gray
Weight 1.66 kg / 3.65 lbs
Dimension of camera 20.96 cm (H) × 15.88 cm (W) × 6.99 cm (D)

Communication

WiFi Wi-Fi 802.11 b/g/n
GSM 3G/4G (2G compatible)
SIM card size Standard
Ethernet Standard wired Ethernet 100 BASE-TX
